7" LED LUMINEDGE Boost Driving light with Dynamic Dual position light
DZ6034W-boost
Delivery:
FOB GUANGZHOU
minimum order:
100 pieces
Stock Time:
40Day
Experience the power of light with CHIMING Luminedge 9″. These 178.5 mm lights feature a dynamic start-up position light in white and amber. The innovative original Luminedge series offers a new unique design of position light . The Luminedge 7″ emits E-mode 3500 lumen, providing 1 lux at a distance of 350 meters. The driving beam pattern ensures optimal visibility with a wide and long-range reach. The lights have a color temperature of 5000-5500 K, offering pleasant illumination in all conditions.
Quantity:

| Type of lamp | LED |
| Pcs LED | 6 |
| Voltage | 10-30VDC |
| Actual effect (W) 13.5V | E-mode:60W; boost:120W |
| Theoretical lumen (Lm) | E-mode:4550LM; boost:9100LM |
| Actual lumen (Lm) | E-mode:3500LM; boost:7000LM |
| 1 lux @ (m) | mode:1LUX@350m; boost:1LUX@500m |
| Kelvin (K) | 5000-5500K |
| IP-class (IP) | IP67&69K |
| Beam pattern | Driving Beam |
| Position light | Dynamic white and Amber |
| Warning Light | N/A |
| Connection | Cable only |
| Cable length (mm) | 30-35CM |
| Material bracket | Stainless steel |
| Material chassi | Aluminum |
| Material lens | Polycarbonate |
| Operating temperature | -40 – +60°C |
| E-mark approval | R149.R148 |
| EMC | ECE R10 |
| Ref. no. | 50 |
| Warranty | 2 years |
