20" Light bar LUMINEDGE Boost Driving light with Dynamic Dual position light
DZ6032L-20 boost
Delivery:
FOB GUANGZHOU
minimum order:
100 pieces
Stock Time:
40Day
CHIMING Luminedge series 20in single row multi-function light bar . One lamp you can get driving light experience , white and amber dynamic start up position light .With anti-UV and anti-scratch lens ,won't been easily scratch and won't turn yellow for years using . Top quality perfectly match with all kinds of vehicle .
Quantity:
| Type of lamp | LED |
| Pcs LED | 12 |
| Voltage | 10-30VDC |
| Actual effect (W) 13.5V | E-mode:70W; boost:120W |
| Theoretical lumen (Lm) | E-mode:7200LM; boost:15000LM |
| Actual lumen (Lm) | E-mode:5500LM; boost:11000LM |
| 1 lux @ (m) | E-mode:1LUX@340m boost:1LUX@450m |
| Kelvin (K) | 5000-5500K |
| IP-class (IP) | IP67&69K |
| Beam pattern | Driving Beam |
| Position light | Dynamic white and Amber |
| Warning Light | N/A |
| Connection | DT-6 (5cores） |
| Cable length (mm) | DT-6P:250mm male +250mm female |
| Material bracket | Aluminium and Stainless steel(side and rear bracket) |
| Material chassi | Aluminum |
| Material lens | Anti-UV , Anti-scratch Lens |
| Operating temperature | -40 – +60°C |
| E-mark approval | R149.R148 |
| EMC | ECE R10 |
| Ref. no. | 45 |
| Warranty | 2 years |
